XJT-II Laboratory Leaching Agitator with Variable Speed, Aeration and Temperature Control
Product Overview
The XJT-II Laboratory Leaching Agitator is a bench-top laboratory machine designed for ore leaching, slurry agitation, aerated leaching and hydrometallurgical research. The equipment adopts a compact bench-top structure with stable operation and variable-frequency speed control.
The impeller speed can be continuously adjusted from 0 to 2800 rpm and displayed digitally for accurate laboratory operation. The XJT-II is equipped with an external aeration system to provide air during laboratory leaching tests and better simulate aerated operating conditions.
Key Features
Variable Speed Control: The impeller speed can be continuously adjusted from 0-2800 rpm to meet different laboratory test requirements.
External Aeration System: The external air supply system provides controlled aeration for laboratory leaching and agitation experiments.
Temperature Monitoring and Control: The temperature control system allows real-time monitoring of slurry temperature. An optional 250 W heater can be used for heating and temperature control.
Multiple Tank Capacities: Available capacities include 1.5 L, 3 L and 5 L, suitable for different laboratory testing scales.
Digital Display: The digital control system provides convenient speed adjustment and clear parameter display.
Stable Laboratory Operation: The compact bench-top design and optimized mechanical structure provide stable operation for laboratory testing.
Main Components
Base Frame
Agitating Motor
Impeller
Mixing Tank
Shaft
Shaft Sleeve
Bearing Housing
Control Panel
External Aeration System
Temperature Control System
Heater
Working Principle
The prepared ore slurry is added to the laboratory mixing tank. The motor drives the impeller to rotate and thoroughly mix the solid and liquid phases.
During testing, the impeller speed can be adjusted through the variable-frequency control system. Air can be supplied through the external aeration system when aerated leaching is required.
When temperature-controlled testing is required, the heater can be used to heat the slurry while the temperature control system monitors the temperature.
By adjusting agitation speed, aeration, temperature and testing conditions, researchers can evaluate different laboratory leaching conditions and optimize process parameters.
Applications
Ore Leaching Tests
Laboratory Leaching Experiments
Slurry Agitation Tests
Aerated Leaching Tests
Temperature-Controlled Leaching
Mineral Processing Research
Hydrometallurgical Research
Metallurgical Laboratory Testing
Geological Research
Chemical Laboratory Testing
Technical Specifications
| Item |
Specification |
| Equipment Type |
Laboratory Leaching Agitator |
| Application |
Leaching & Slurry Agitation |
| Tank Capacity |
1.5 / 3 / 5 L |
| Impeller Speed |
0-2800 rpm, adjustable |
| Impeller Diameter |
31 / 39 / 48 mm |
| Feed Particle Size |
0.05-0.2 mm |
| Overall Dimensions |
450 * 340 * 475 mm |
| Weight |
68 kg |
| Air Pump |
CX-0098 |
| Heater |
AC 220 V, 250 W |
| Main Shaft Motor |
AO2-5622 |
| Motor Voltage |
Three-phase 220 V |
| Speed Control |
Variable Frequency Control |
Packaging & Shipping
Export Wooden Crate: Strong plywood/wooden crate for safe transportation.
Secure Fixing: Equipment is securely fixed and protected inside the crate.
Protective Packing: Cushioning and moisture protection help reduce damage during transit.
Export Ready: Suitable for sea, air and land transportation.
Customized Packing: Packing methods can be adjusted according to shipping requirements.
Frequently Asked Questions
What is the XJT-II Laboratory Leaching Agitator used for?
The XJT-II is designed for laboratory ore leaching, slurry agitation, aerated leaching and hydrometallurgical research.
What is the maximum impeller speed?
The impeller speed can be adjusted from 0 to 2800 rpm.
What tank capacities are available?
The standard tank capacities are 1.5 L, 3 L and 5 L.
Does the XJT-II have an aeration system?
Yes. The machine is equipped with an external aeration system for laboratory aerated leaching tests.
Does the machine support temperature control?
Yes. The equipment includes a temperature control system and can be equipped with a 250 W heater.
What is the feed particle size?
The specified feed particle size is 0.05 -0.2 mm.
